| Number of Simultaneous Recording Tracks | 2 (STEREO mode), 4 (4CH mode), 2 (MTR mode) |
| Recording Time (4GB SDHC) | Approx. 68 hours (MP3 44.1 kHz / 128 kbps stereo track) |
| Recording Time (4GB SDHC) | Approx. 380 minutes (WAV 44.1 kHz / 16-bit stereo track) |
| Max. File Size of Simultaneous Recording | 2GB |
| Projects | 1000/card |
| Locate Function | Hours/Minutes/Seconds/Milliseconds |
| Effects Modules | STEREO / 4CH Mode: LO CUT, COMP/LIMITER |
| Effects Modules | MTR Mode: PRE AMP module, EFX module |
| Number of Types | 53 |
| Number of Patches | 60 |
| Number of Tuners | Chromatic, Guitar, Bass, Open A/D/E/G, DADGAD |
| Metronome Sound Sources | 5 |
| Variable Beat | 1/4 - 8/4, 6/8, unaccentuated |
| Tempo Range | 40.0 - 250.0 BPM |
| A/D Conversion | 24-bit x 128 oversampling |
| D/A Conversion | 24-bit x 128 oversampling |
| Recording Media | SD Card, SDHC Card |
| Data Type | MP3 Format |
| Data Type | WAV Format |
| Inputs | XLR (balanced input) / standard phone (unbalanced input) combo jack |
| Input Impedance | (Using balanced input) 3 kOhms or more, pin 2 hot |
| Input Impedance | (Using unbalanced input) 470 kOhms or more |
| Input Gain | (Using balanced input) -16 dB to +43 dB, (Using unbalanced input) -30 dB to +32 dB |
| Built-In Stereo Mic | Input gain: -16 dB to +51 dB |
| Built-In Stereo Mic | Sensitivity: -45 dB/1 Pa at 1 kHz |
| Built-In Stereo Mic | Unidirectional condenser microphone, |
| Built-In Stereo Mic | Maximum sound pressure input: 140 dB SPL |
| External Mic | Input gain: -16 dB to +51 dB |
| External Mic | Mini stereo phone jack |
| External Mic | Input impedance: 2 kOhms or more |
| Line/Phone | PHONE: 20 mW + 20 mW (into 32Ohms load) |
| Line/Phone | LINE rated output level: -10 dBu |
| Line/Phone | LINE Output load impedance: 10 kOhms or more |
| Phantom Power | 48V, 24V, OFF |
| USB | USB 2.0 |
| Power Requirements | DC 5V 1A AC from AC adapter (ZOOM AD-14), 2x AA batteries |
| Batteries | IEC R6 (size AA) x 2 |
| Continuous Recording Time | STEREO Mode (About 6 Hours) |
| Continuous Recording Time | STAMINA Mode (About 10 Hours) |
