JVC GY-HM180U 4K Cam HD-SDI Handheld Camcorder with Integrated 12x Lens

Be the first to write a review

1/2.3" 12.4MP CMOS Sensor with 12x Optical and 24x Digital Zoom Lens
Record UHD 4K 24/30p at 150 or 70 Mb/s
Dual SDHC/SDXC Memory Card Slots
Live UHD 4K Output via HDMI
120 fps HD for Smooth Slow Motion
Simultaneous Full-Size & Proxy Recording
Two XLR Audio Inputs with Phantom Power
3G-SDI & HDMI Triggers External Recorder

Screen Size:: 3.5"

Screen Size:: The size of the screen listed by height and width.

View All Attribute Definitions

Compatible Media:: SD/SDHC/SDXC [U3/V30 or Faster Recommended]

Compatible Media:: A storage medium that is compatible with your portable device, in a form that can easily be removed or accessed by a PC such as a type of memory card that is compatible with your camera.

View All Attribute Definitions

Megapixels:: Effective: 12.4 Megapixel

Megapixels:: A megapixel is one million pixels. It is commonly used to describe the resolution of digital cameras. For example, a 7.2 megapixel camera is capable of capturing roughly 7,200,000 pixels. The higher the megapixel number, the more detail the camera can capture. Therefore, the megapixel count is a significant specification to look for when buying a digital camera.

View All Attribute Definitions

Viewfinder Type:: Built-In Electronic (LCD)

Image Sensor Size:: 1/2.33"

Image Sensor Size:: Refers to the actual physical size of the imaging sensor in the camera. A sensor that has the same dimensions as a 35mm frame of film is considered to be "full" frame. Other smaller sensor sizes are described in terms relative to a "full" sized sensor. (e.g. an APS-C 1.5x crop sensor)

View All Attribute Definitions

Image Sensor Type:: CMOS Sensor

Lens Filter Size:: 62mm

Lens Filter Size:: The size of the filter that fits the lens.

View All Attribute Definitions

Focal Length:: 35mm equivalent: 29.6mm-355mm

Focal Length:: Focal Length

View All Attribute Definitions

Maximum Aperture:: f/1.2 to f/3.5

Maximum Aperture:: How wide a lens can be opened.

View All Attribute Definitions

OVERVIEW

The new GY-HM180 sets a new benchmark for professional compact cameras with improved recording features over its predecessor. With full professional controls and an integrated 12x zoom lens it delivers stunning 4K Ultra HD video recordings directly to economical SDHC/SDXC memory cards. And, should you need to go-live, it you can output 4K through its HDMI connector, or HD through the newly added 3G-SDI output.

Integrated 12x Ultra HD Lens, 1/2.3-inch CMOS Sensor

Ultra high quality imagery begins with a precision 12x F1.2-3.5 optical zoom lens (35mm equivalent: 29.5-354mm). JVC's 4K CMOS sensor with 12.4M pixels delivers high sensitivity and excellent performance over a wide range of lighting conditions. Details are crisp and accurate throughout the entire image plane. When shooting in the HD mode, Dynamic Zoom combines optical zoom and pixel mapping to create seamless and lossless 24x zoom. This allows the camera to have a long zoom range while retaining its small form factor. Shooters will also appreciate the convenient ND filter wheel: 0, 1/4th and 1/16th positions.

4K Ultra HD Recording at 150Mbps and Live Output

Working with 4K has never been easier! Insert an SDHC or SDXC (UHS-I Speed class3) memory card and record hours of 4K Ultra HD (3840 x 2160) material. Recordings are made using the Quicktime (.MOV) file format and are compatible with many popular editing systems. Connect a 4K Ultra HD monitor with a single HDMI cable, and view the camera's live 4K signal. You can also play back recorded files directly from the camera. The GY-HM180 also downconverts UHD signals to standard HD for output through the built-in HDMI connector, or through the 3G-SDI connector.

4:2:2 Full HD recording at 50Mbps

The GY-HM180 records 4:2:2 HD signals up to 60p at 50Mbps making it an ideal camera for general HD production work. 50Mbps files are stored in the Quicktime (.MOV) format for easy editing. Conventional AVCHD (4:2:0) recording is also possible, providing wide editing compatibility in an array of standard HD and SD formats.

Dual SDHC/SDXC Card Slots

Dual SDHC/SDXC card slots make the GY-HM180 a truly versatile camcorder, offering such benefits as simultaneous recording and relay recording. In relay recording mode, you can shoot continuously and seamlessly over multiple cards. When one card is full, the camcorder switches seamlessly and automatically to the other card. And because cards are hot swappable, there is in effect no limit to the continuous shooting time in any mode, even with lower capacity cards.

Clip Continuous Recording

In normal recording, when the recording stops, the image, audio, and accompanying data from the start until the end of the recording are recorded as one "clip" on the SD card. This mode allows you to consolidate several rounds of "start/stop recording" into one clip.

For example, in normal recording three clips are generated as Recording 1, Recording 2, and Recording 3. However, recording in this mode the camera generates only one clip.

Web Friendly (Proxy) file formats

Lower resolution H.264 files (480x270p and 960x540p) may be recorded simultaneously with full HD files. These files are significantly smaller than HD files, and thus are very suitable for immediate posting to the web. A file recorded in the 960 x 540 mode is approximately 1/10th the size of a full HD file recorded at 35 Mbps, and therefore takes a fraction of the time to post. The smaller files may be quickly imported to an iPad for easy editing using iMovie or Pinnacle Studio. Transporting video to the web or back to the studio has never been faster.

Product Reviews

There are no reviews for this product.

Write a review

Specifications

Brand
JVC Professional Video

Display & Viewfinder
Screen Size:	3.5"
Screen Size: The size of the screen listed by height and width. View All Attribute Definitions
Viewfinder Resolution:	1,560,000 Dots
Display Type:	Articulating LCD
Display Type: The type or brand of the screen. View All Attribute Definitions
Monitor Resolution:	920,000 Dots
Monitor Resolution: A measurement of the LCD Monitor's resolution not by width by height, but rather the total amount of dots. View All Attribute Definitions

Detailed Specifications
Compatible Media:	SD/SDHC/SDXC [U3/V30 or Faster Recommended]
Compatible Media: A storage medium that is compatible with your portable device, in a form that can easily be removed or accessed by a PC such as a type of memory card that is compatible with your camera. View All Attribute Definitions
Megapixels:	Effective: 12.4 Megapixel
Megapixels: A megapixel is one million pixels. It is commonly used to describe the resolution of digital cameras. For example, a 7.2 megapixel camera is capable of capturing roughly 7,200,000 pixels. The higher the megapixel number, the more detail the camera can capture. Therefore, the megapixel count is a significant specification to look for when buying a digital camera. View All Attribute Definitions

Physical Specifications
Dimensions:	12.1" x 7.5" x 5.9"
Dimensions: The measurements of an object. View All Attribute Definitions
Weight:	2.43lbs
Weight: The physical weight of the item without packaging. View All Attribute Definitions

Interface
Memory Card Slot:	Dual Slot: SD/SDHC/SDXC [U3/V30 or Faster Recommended]

Viewfinder Specifications
Viewfinder Type:	Built-In Electronic (LCD)

Power System
Battery Type:	JVC BN-VF823
Battery Type: The type of battery for a device. Some cameras use single use alkaline while others use rechargeable lithium batteries. View All Attribute Definitions

Brand
Brand:	JVC

Focusing Control
Focus Modes:	Automatic Manual Focus
Focus Modes: The types of focus modes an item has. View All Attribute Definitions

Camera Attributes
Audio Recording:	AVCHD: 2-Channel 16-Bit 48 kHz LPCM Audio
Image Stabilization:	Optical in Integrated Lens
Image Sensor Size:	1/2.33"
Image Sensor Size: Refers to the actual physical size of the imaging sensor in the camera. A sensor that has the same dimensions as a 35mm frame of film is considered to be "full" frame. Other smaller sensor sizes are described in terms relative to a "full" sized sensor. (e.g. an APS-C 1.5x crop sensor) View All Attribute Definitions
Image Sensor Type:	CMOS Sensor
Operating Temperature:	0°C to 40°C
Recording File Format (Video):	H.264 4:2:2 3840 x 2160 at 23.98/25/29.97 fps [70 to 150 Mb/s] H.264 1920 x 1080p at 23.98/25/29.97/50/59.94/100/ fps [50 Mb/s] 1920 x 1080i at 50/59.94 fps [50 Mb/s] 1280 x 720 at 50/59.94 fps [35 Mb/s] 960 x 540 at 23.98/25/29.97 fps 720 x 480i at 59.94 fps 720 x 576i at 50 fps 480 x 270 at 23.98/25/29.97 fps AVCHD 1920 x 1080p at 50/59.94 fps [28 Mb/s] 1920 x 1080i at 50/59.94 fps [24 Mb/s] 720 x 576i at 50 fps [8 Mb/s] 1440 x 1080i at 50/59.94 fps [9 Mb/s] 720 x 480i at 59.94 fps [8 Mb/s] 720 x 576i at 50 fps [8 Mb/s]

Lens Specification
Lens Filter Size:	62mm
Lens Filter Size: The size of the filter that fits the lens. View All Attribute Definitions
Focal Length:	35mm equivalent: 29.6mm-355mm
Focal Length: Focal Length View All Attribute Definitions
Maximum Aperture:	f/1.2 to f/3.5
Maximum Aperture: How wide a lens can be opened. View All Attribute Definitions
Focus Type:	Auto and Manual Focus
Focus Type: The type of focus of the lens from full manual control to auto focus. View All Attribute Definitions
