Video Terminal | Signal configuration: NTSC standard color video signals; Impedance: 75 ohm; Signal level: 1 Vp-p (composite); Horizontal resolution; Self recording/playback: Max. 530 TV lines (screen center); Camera EEout catalog value: Approx. 530 TV lines (screen center) |
USB Terminal | mini-AB: Hi-Speed USB supported |
Audio | Types of signals: Stereo audio signal; Impedance: Less than 3 k ohm; Signal level: -10 dBV (with 47 k ohm load); Frequency characteristic: 60 Hz to 16 kHz (range between 1 kHz reference ±3 dB) |
Image Stabilization | Intelligent IS in Auto/Baby mode: Dynamic IS (default), Powered IS, Macro IS, Tripod Mode; IS Modes other than Intelligent IS; Dynamic IS and Powered IS settings can be made manually in P/High-brightness priority/SCN*1/ Cinema Mode: Standard IS, IS Off; Angular velocity detection (using piezoelectric vibration sensor) and hybrid by sensor based movement vector detection supported |
Maximum Recording Time | 32GB Internal Flash Drive in MP4: 4 Mbps (1280 x 720): 17 hrs. 20 min. 17 Mbps (1920 x 1080): 4 hrs. 10 min. 24 Mbps (1920 x 1080): 2 hrs. 55 min. 35 Mbps (1920 x 1080): 2 hrs. |
Frame Rate | 60P/30P/24P |
Minimum Illumination | P mode: Approx. 5 lux; Low Light mode: Approx. 0.4 lux |
Total Pixels | Approx. 3.28 Megapixels |
