Atomos Sumo PRO-19 4K HDR Monitor

OVERVIEW

The Atomos Sumo PRO-19 is a versatile 19" HDR monitor, 4K recorder, and live switcher engineered to bridge on-set production and post-production workflows. Built around a daylight-viewable 1200 cd/m² display with 10-stop dynamic range and 10-bit processing, it provides precise log-to-HDR visualization for video village, DITs, first ACs, and color-critical studio environments.

Live Switching & High-End Recording

Performs live SDI quad-switching and 5-channel ISO recording in resolutions up to 8K30.

Records 8K raw, ProRes RAW, 10-bit Apple ProRes, H.265, and DNxHR directly to CFexpress Type B cards or external USB-C drives.

Converts real-time LOG signals with custom 3D LUT previews (.cube) loaded via CFexpress or USB-C.

Monitoring & Camera Control

Integrates essential image evaluation tools including waveform, focus peaking, EL Zone false color, RGB parade, and vectorscope.

Provides direct touchscreen camera control for key functions—such as ISO, shutter, white balance, and touch focus—on supported Sony, Canon, Panasonic, Nikon, and Fujifilm cameras.

Supports hardware calibration via Calibrite Display Pro/Plus to ensure long-term color accuracy.

I/O, Wireless & Cloud Connectivity

Cross-converts seamlessly between HDMI 2.0 and Quad 3G/6G/12G-SDI in any combination.Features Wi-Fi 6E, Gigabit Ethernet, and NDI|HX3 support, alongside camera-to-cloud integration with Frame.io, Dropbox, and ATOMOSphere.

Synchronizes timecode via BNC (LTC/Genlock), AirGlu RF, and Bluetooth.

Captures balanced analog audio through dual full-size XLR inputs with dedicated gain and frame-delay adjustments.

Production-Grade Hardware

Built with a rugged aluminum chassis featuring multiple 1/4"-20 and 3/8"-16 threads, a rear 100 x 100 VESA mount, six programmable front-panel function buttons, and a desktop stand.

Operates via the included 4-pin XLR AC adapter, with support for optional dual V-Mount or Gold Mount battery plates for redundant field power.
