Sennheiser XSW-D Portable ENG Set Digital Cam-Mount Combo Mic Setup 2.4 GHz
Sennheiser- Product #:
- SEN2016
- Manufacturer #:
- 508490
- UPC:
- 615104317796
- Plug & Record Set for Vlogger
- ME 2-II Omnidirectional Lav Mic
- Miniature Bodypack Transmitter
- One touch ease-of-use
- 2.4 GHz digital transmission for worldwide operation
- 75m range (250ft) in optimal conditions
- Up to 5 hours battery life on a single charge
- Switch between multiple transmitters linked to one receiver
- Configure any combination of transmitters and receivers
- Mute from either transmitter or receiver
Overview
One-touch ease-of-use wireless audio set that utilizes a digital transmission to seamlessly link audio sources. Equipped with XLR and 3.5mm (1/8”) transmitters, this elegant solution makes capturing dialogue on a DSLR easier than ever before while maintaining a reliable connection.
Product Reviews
There are no reviews for this product.
Specifications
Brand | |
---|---|
Sennheiser |
Microphone Specifications | |
---|---|
Form Factor: | Lavalier |
Polar Pattern: | Omnidirectional |
Operating Voltage: | 7.5 V |
Output Connectors: | 1 x 1/8" / 3.5 mm TRS Male Unbalanced (Lockable) |
Capsule: | Electret Condenser |
Sound Field: | Mono |
Equivalent Noise Level: | 36 dB |
Sensitivity: | 20 mV/Pa |
Maximum SPL: | 130 dB SPL Peak |
Frequency Range: | 50 Hz to 18 kHz |
Detailed Specifications | |
---|---|
Type of Microphone: | Lavalier & Handheld Combo |
|
|
RF Carrier Frequency Range: | 2400 to 2483.5 MHz |
|
|
Maximum Operating Range: | 250' / 76.2 m (Line of Sight) |
Cable Length: | 5.25' / 1.6 m |
|
Physical Specifications | |
---|---|
Dimensions: | 1.1 x 3.4 x 0.9" / 28 x 86 x 24 mm |
|
Wireless Transmitter Specifications | |
---|---|
AF Frequency Response: | 80 Hz to 18 kHz |
Power Supply: | Battery, Bus Power (USB) |
RF Output Power: | 10 mW |
Operating Temperature: | 14 to 131°F / -10 to 55°C |
Material: | Plastic |
Brand | |
---|---|
Brand: | |
Brand: | Sennheiser |
Wireless Receiver Specifications | |
---|---|
Power Supply: | Battery, 1 x USB Type-C (Bus Power, Charging) |
Audio Output: | 12 dB (Consumer Level) |
Operating Temperature Range: | 14 to 131°F / -10 to 55°C |
Antenna Connector: | 1 x Internal |
In The Box
- XSW-D 3.5mm (1/8”) transmitter
- XSW-D XLR Female transmitter
- XSW-D 3.5mm (1/8”) receiver
- ME2-II clip-on lavalier mic
- 3.5mm (1/8") coiled cable
- Cold shoe mount
- Belt clip
- USB-A to USB-C charging cable
