Four New Canon ‘L’ Lenses and more!

Aug 26, 2010

Ok! If the 60D announcement wasn't enough for you already, Canon also released four new lenses this morning along with two new teleconverters. Lots to cover and the lenses were interesting enough that I decided they needed their own post. The new lenses are an EF 70-300mm f/4-5.6L IS, EF 8-15mm f/4L fisheye zoom, EF 300mm f/2.8L IS II, and 400mm f/2.8L IS II. The two new teleconverters are Canon Extender 1.4x III and Canon Extender 2x III. While Canon has annoucned MSRP for the lenses, the retail price is always much lower, so we are waiting for that pricing before taking pre-orders. I will let everyone know when these lenses are available for pre-order. All six of these products use a brand new fluorine coating that improves optical quality. The fluorine coating also makes the optical surfaces more water/oil resistant, and in turn easier to clean. More pictures, thoughts, and official press release after the break.

EF 70-300mm f/4-5.6L IS

Wow I totally wasn't expecting this lens at all. There were lots of rumors flying around about a new 100-400mm replacement. I only read a couple things about a 70-300mm replacement, but I didn't expect it to be an L-Series lens! This is really cool because there is nothing else like this lens, it has created its own class. There is now a telephoto zoom lens with the world's best optics in a lightweight and compact size. A new complex floating element has decreased the minimum focusing distance by more than a foot! This lens will be here at the end of October.

EF 8-15mm f/4L Fisheye Zoom

To me this is the most exciting lens out of the group of new lenses. One other manufactuer makes a fisheye zoom, but it is not a full frame lens. This Canon lens is revolutionary. It is the first full frame fisheye zoom with a constant aperture and again, the world's best optics. I was expecting a 14-24, and still do at some point, but this lens caught everyone off guard. Good work on Canon's part by keeping this exciting product under wraps until its announcement. We should have one in December.

On a full frame sensor this lens produces a circular image.

When used on an APS sized sensor, the image still has a fisheye effect, but fills the entire frame.

300mm f/2.8L IS II and 400mm f/2.8L IS II

While these lenses are incredible and the big lenses always get the "oohs" and "ahhs" everyone was expecting these lenses for a long time. Still there are some very noteable improvements from the previous versions. Weight has been reduced in both lenses. Throw in improved coatings and Image Stabilization in both models and you have two of the best super-telephoto lenses on the market for professional use. An exciting new feature on both lenses is "PF" (Power Focus) mode that allows manual rack focusing with the turn of a knob. This will help moviemakers that want to use super-telephoto lenses. They should start showing up sometime in December. Expect the 500mm and 600mm lenses to be updated at some point soon too.

The new 300mm f/2.8 weighs 8% less than the old 300mm f/2.8L IS!

The new 400mm f/2.8 weighs an astonishingly 28% less than the previous model!

Canon Extender 1.4x III and Canon Extender 2x III

Just like the professional super telephoto lenses they are usually used on, these extenders were expected for awhile. The fluorine coating is new, but there are some other new features as well. A newly developed microcomputer allows for faster and more precise AF functions, especially with newer "IS II" lenses (like the EF 70-200mm f/2.8L IS II). Both will be here in December.

Some really great stuff from Canon today. I was shocked to not see a 14-24mm f/2.8L lens or the highly anticipated 24-70mm f/2.8L IS. There were lots of rumors floating around about both lenses and some others. I believe we will see both of those lenses next year. There will still possibly be a 1Ds Mark IV at Photokina, but I don't think there will be any additional lenses. Hope I am wrong! Stay tuned for reviews and updates on pre-orders.

Here is Canon's official press release on the lenses.

Canon Focuses On Professionals By Introducing Six New L-Series EF Lenses And Accessories

Canon Introduces the World's Widest Fisheye Zoom Lens, a New Telephoto Zoom Lens and Two New Super Telephoto Lenses with Optional New Extenders

LAKE SUCCESS, N.Y., August 26, 2010 – Canon U.S.A., Inc., a leader in digital imaging, rounds out its Summer product introductions with four new L-series lenses and two new accessory extenders for professionals and advanced amateurs. Leading the introductions, the EF 8-15mm f/4L Fisheye USM lens is the world's widest fisheye zoom lens, providing professional photographers and cinematographers with a unique optical tool for capturing 180? angle-of-view shots on all EOS Digital SLR cameras. Photographers looking for a broad focal length range with excellent image quality will enjoy the Company's first L-series 70-300mm telephoto zoom lens, the new EF 70-300mm f/4.5-5.6L IS USM lens, delivering outstanding sharpness, contrast and color fidelity in a compact, lightweight form factor. Canon is introducing two new versions of its popular super telephoto lenses, the new EF 300mm f/2.8L IS II USM and EF 400mm f/2.8L IS II USM super-telephoto lenses delivering incredible image quality at all apertures for professional photojournalists, sports and wildlife photographers. For professionals and advanced amateurs looking to push their L-series Canon telephotos to the limit, the Company is proud to upgrade its two popular extenders with the new Canon Extender EF 1.4x III and Extender EF 2x III for additional telephoto reach and exceptional clarity. Photographers will immediately notice that the latest Canon L-series telephoto lenses and extenders have a more neutral white tone compared to earlier models. This new shade of white will be used with all L-series telephoto lenses and extenders beginning in the second half of 2010. The introductions of these Canon lenses have been timed with Canon's latest camera introduction, the Canon EOS 60D Digital SLR camera, designed for advanced amateurs and emerging professional photographers.

"Canon's core has always been our optics, and we are constantly challenging ourselves to produce better and more advanced optical systems for our customers. These six new products advance the state of the art in Canon lens technology and provide new and innovative tools for professionals and advanced amateur photographers," stated Yuichi Ishizuka, executive vice president and general manager, Consumer Imaging Group, Canon U.S.A.

Canon EF 8-15mm f/4L Fisheye USM lens

With its unique focal length range, the EF 8-15mm f/4L USM is the world's widest fisheye zoom lens. It delivers 180§ diagonal angle of view images for all EOS SLR cameras with imaging formats ranging from full-frame to APS-C, and provides 180? circular fisheye images for full-frame EOS models. Professional photographers and cinematographers will revel in the unique perspectives afforded to them through this lens, particularly when coupled with the highly popular full-frame EOS 5D Mark II DSLR camera. Canon's new Fisheye zoom lens features both UD and aspherical lens elements to enhance image quality and is equipped with rubber gaskets and seals to enhance weather resistance. Canon's proprietary SWC (Sub Wavelength Structure Coating) is used to minimize flare and a new fluorine anti-smear coating is applied to the front and rear elements to make lens cleaning easier than ever.

The Canon EF 8-15mm f/4L Fisheye USM lens is expected to be available in January of 2011 for an approximate retail price of $1,400.

Canon EF 70-300mm f/4-5.6L IS USM lens

Compact and lightweight, yet durable and professionally sharp, the EF 70-300mm f/4-5.6L IS USM lens is the ideal telephoto zoom lens for advanced amateurs looking for that extra reach to bring a subject in tight and close. Providing the power and durability to maximize every shooting opportunity, the Canon EF 70-300mm f/4-5.6L IS USM lens features two UD ultra-low dispersion glass elements for enhanced sharpness, L-series weather and dust sealing for shooting in harsh conditions, improved mechanical design, and streamlined ergonomics to help avoid inadvertent mode switch operation. The shapes of the lens elements and their coatings have been optimized to minimize ghosting and flare to produce high-contrast and high-resolution throughout the zoom range. A sophisticated floating system optical formula optimizes image quality at all distance settings and reduces minimum focusing distance by more than a foot. An updated optical image stabilization system compensates for camera shake up to an equivalent of four full shutter-speed steps, a full step improvement compared to earlier EF 70-300mm lenses. A new fluorine anti-smear coating is applied to the front and rear elements.

The Canon EF 70-300mm f/4-5.6L IS USM lens is expected to be available toward the end of October for an approximate retail price of $1,500.

Canon EF 300mm f/2.8L IS II USM lens

The Canon EF 300mm f/2.8L IS II USM is the 6th generation of a venerable family of Canon 300mm f/2.8 lenses that began in 1974, and have become famous for their exceptional sharpness, contrast and color fidelity. Ideal for a wide range of applications ranging from professional photojournalism and sports photography to nature and wildlife, Canon's 300mm f/2.8 lenses have always led the industry with new technical advances in every generation. The EF 300mm f/2.8L IS II USM lens carries on this tradition with improved image quality, lighter weight, improved Image Stabilization and enhanced durability making it a great option for handheld work in the field. The optical formula of the new lens has been upgraded with the inclusion of two fluorite lens elements for improved image quality and reduced chromatic aberration. Helping to reduce arm fatigue, Canon has reduced the overall weight of the lens by 8 percent to 82.9 oz., making it the lightest weight lens in the Canon EF 300mm f/2.8 series. The Image Stabilizer provides an equivalent of approximatel y four full shutter speed steps of shake compensation and has been enhanced through the incorporation of a rolling-ball-friction system in place of sliding parts in the compensation optics barrel for a minimum-friction structure. The overall durability of the lens has also been enhanced through increased usage of magnesium alloy and titanium for lens barrel components, together with weather sealing for all exterior joints and switches and a new fluorine anti-smear coating applied to the front and rear elements.

The Canon EF 300mm f/2.8L IS USM lens is expected to be available in December for an approximate retail price of $7,000.

Canon EF 400mm f/2.8L IS II USM lens

Quintessential for many sports assignments including baseball, football, soccer and golf, Canon's professional 400mm f/2.8 lenses provide the light gathering capability and long telephoto reach that photographers need to freeze the action and fill the frame . The Canon EF 400mm f/2.8L IS II USM is the 5th generation in Canon's 400mm f/2.8 series and the successor to the current EF 400mm introduced in 1999. The new lens has been engineered for the ultimate in optical performance through the use of two fluorite lens elements for improved quality and reduced chromatic aberration. Helping photographers in the field, Canon has reduced the overall weight of the lens by a substantial 28 percent from 189.4 oz to 135.8 oz, making it Canon's lightest weight 400mm f/2.8 lens ever. The Image Stabilizer provides an equivalent of approximately four full shutter speed steps of shake compensation and has been enhanced through the incorporation of a rolling-ball-friction system in place of sliding parts in the compensation optics barrel for a minimum-friction structure. The overall durability of the lens has also been enhanced through increased usage of magnesium alloy and titanium for lens barrel components, together with weather sealing for all exterior joints and switches and a new fluorine anti-smear coating is applied to the front and rear elements.

The Canon EF 400mm f/2.8L IS USM lens is expected to be available in December for an approximate retail price of $11,000.

Canon Extender EF 1.4x III & Canon Extender EF 2x III

The two new EF extenders are direct replacements of the current extenders offered by Canon as essential accessories for professionals. These new extenders have been designed to provide faster autofocusing and improved autofocus precision with compatible EF lenses. Each extender includes an anomalous dispersion lens element for reduced chromatic aberration and enhanced optical image quality. Each extender also features a newly developed microcomputer that increases AF precision when the extenders are used with a IS Series II EF super-telephoto lens. Both extenders are equipped with rubber gaskets and seals to enhance weather resistance. A new fluorine anti-smear coating is applied to the front and rear elements of both extenders.

The Canon Extender EF 1.4x III & Canon Extender EF 2x III are expected to be available in December for an approximate retail price of $500 each.

New Lens Features

In addition to an anti-reflection multi-coating, the front and rear elements of all newly announced EF lenses and extenders are treated with Canon's new fluorine anti-smear lens coating. The fluorine layer is highly oil- and water-repellent so that any oil smears or water droplets on the lens can be wiped off quickly and easily without the aid of solvents using a soft dry cloth. These four new lenses and two new extenders are the first of their type to employ fluorine coating, and it is expected that this new feature will enhance the usability of the lenses during adverse shooting conditions.

The new Series II EF super-telephoto lenses can correct camera shake up to four full shutter speed steps, compared to two shutter speed steps for the original versions. This improvement is made possible by a new low-friction stabilizer mechanism that is not only more efficient than the previous design but also smaller and lighter. Other enhancements to the IS systems of both new super telephoto lenses have enabled quieter operation ideal for use during video capture.

Providing professional sports and wildlife photographers with greater tracking flexibility, Canon has introduced a third Image Stabilization mode option to its new EF 300mm f/2.8L IS II USM and EF 400mm f/2.8L IS II USM lenses. When mode 3 is selected on the lens, the image stabilization effect will not be seen in the viewfinder. When the shutter button is pressed halfway, the lens will begin detecting camera or lens movement and only during exposure, when the shutter is fully depressed, will the Image Stabilization engage and provide the equivalent of four stops faster compensation for blur-free images. The new Mode 3 is particularly useful when a photographer does not want to see the IS working in the viewfinder while tracking a moving subject.

Helping moviemakers achieve smoother and more appealing focus shifts when filming on EOS DSLR cameras, Canon has included a new Power Focus (PF) mode on the Company's two new super telephoto lenses. This mode allows manual rack focusing to be operated smoothly by turning a playback ring that is normally used for the focus preset function. Both low-speed and high-speed focus shifting are available.

Additionally, a new security slot attachment has been included on both new super-telephoto lenses to allow a wire-type security lock to be easily affixed, a great safety feature for professionals shooting from high vantage points above arenas and crowds.

About Canon U.S.A., Inc.

Canon U.S.A., Inc., is a leading provider of consumer, business-to-business, and industrial digital imaging solutions. Its parent company, Canon Inc. (NYSE:CAJ), a top patent holder of technology, ranked fourth overall in the U.S. in 2009†, with global revenues of US $35 billion, is listed as number six in the computer industry on Fortune Magazine's World's Most Admired Companies 2010 list, and is on the 2009 BusinessWeek list of "100 Best Global Brands." Canon U.S.A. is committed to the highest levels of customer satisfaction and loyalty, providing 100 percent U.S.-based consumer service and support for all of the products it distributes. At Canon, we care because caring is essential to living together in harmony. Founded upon a corporate philosophy of Kyosei – "all people, regardless of race, religion or culture, harmoniously living and working together into the future" – Canon U.S.A. supports a number of social, youth, educational and other programs, including environmental and recycling initiatives. Additional information about these programs can be found at www.usa.canon.com/kyosei. To keep apprised of the latest news from Canon U.S.A., sign up for the Company's RSS news feed by visiting www.usa.canon.com/rss.

###

† Based on weekly patent counts issued by United States Patent and Trademark Office.

All referenced product names, and other marks, are trademarks or registered trademarks of their respective owners.

Availability, prices, and specifications of all products are subject to change without notice. Actual prices are set by individual dealers and may vary.
